8 ADJUSTMENTS
78 Rev. 01/2015
8.5.2 Brief Overview of Parameters
In the following table, you will find a brief overview of the ignition controller's configurable
parameters. For more detailed information about the individual parameters, see the
corresponding sections.
Display of parameters
The parameters indicated with a star (*) are dependent on the settings of
other parameters and are not shown in specific instances. Detailed
information on the display of these parameters can be found in the
corresponding sections.
No. Parameter Function Configuration
1 SEQ. NUMBER The sequence number reflects the
engine's configuration and must be set
according to the connected engine.
see Set Sequence
Number on page
80
2 RESET BTDC Angular position of the reset signal from
the upper dead center of the first
cylinder
see Set Reset
Position on page
84
3 OVERSPEED Overspeed value, above which the
ignition is switched off if exceeded.
see Set Overspeed
on page 84
4 SECURITY SPEED Security speed, below which the ignition
can be switched on or off via the digital
input if set to Switch Start/Stop function.
see Set Security
Speed on page 85
5 MISFIRE RATE Maximum permissible misfire rate,
above which the engine will be switched
off.
see Set Misfire
Rate on page 86
6 CYL TO CYL Activate or deactivate cylinder-to-
cylinder alignment
see Activate
Cylinder-to-
Cylinder Alignment
on page 87
7 CONTACT I/P Use of digital input for switching the
ignition on or off (function Switch
Start/Stop) or for operating with two
different schedules (function Switch
A/B)
see Select Function
for Digital Input on
page 87
8 POT TIMING Activate or deactivate the potentiometer see Activate
Potentiometer on
page 88
