Rev. 01/2015 64
Operational safety!
The MIC500 ignition controller must first be correctly configured for the
engine being used before you can start the engine.
An incorrect configuration can result in damage to the engine.
Before using the MIC500 series ignition controller, all parameters relevant to the engine and the
application must be configured. This parameterization can be carried out via a computer
(PC/laptop) using Ignition Control software. You can also use a hand-held programmer available
from MOTORTECH (P/N 06.05.008) as an option.
In addition, you receive information about the current status of your engine via the Ignition
Control software or the hand-held programmer.
For help with installation and general operating instructions on Ignition Control, read chapter
Ignition Control on page 64. For general operating instructions on the hand-held programmer,
read chapter Hand-Held Programmer on page 69.
8.1 Ignition Control
8.1.1 System Requirements Ignition Control
The following minimum requirements must be met for the Ignition Control software:
– RS232 interface; alternatively USB 1.1 with a USB to RS232 converter
– Screen with at least QSVGA resolution (400 x 300 pixels)
– Operating system: Windows 2000 / NT / XP / 7
8.1.2 Installing Ignition Control
Explosion hazard!
Use the RS232 interface solely in a non-explosive atmosphere.
Reinsert the RS232 interface cover after each usage and tighten it with a
tightening torque of 1 Nm (0.7 lb-ft).
If you want to program the ignition controller from a PC or laptop, the Ignition Control software
from the supplied storage device (USB flash drive or CD-ROM) must first be installed on the
computer.
8 ADJUSTMENTS
