5.3 Installation of the Ignition Controller
Risk of damage!
The device must not be installed directly on or at the engine, as vibration
and heat may cause damage to electronic components.
The installation of the MIC500 ignition controller is implemented on a fixed bracket or a wall
near the engine. Always use the included vibration dampers and the ground strap. The
installation location of the device must be selected so that the distance to the pickup installed
on the engine ensures a reliable signal transmission to the ignition controller, and so that there
is adequate space for maintenance and repair work. Also ensure adequate space for the
connection wiring. The mechanical specifications must be complied with. The ground strap
serves to ground the ignition controller and must be used accordingly. Ensure a flawless
electrical connection for this purpose.
Installation locations where strong vibrations or ambient temperatures of below -40 °C (-40 °F)
or above +70 °C (+158 °F) are present are not permissible and result in the warranty being
voided.
