4 PRODUCT DESCRIPTION
22 Rev. 01/2015
Inputs and outputs Values
Ignition coil outputs Output voltage: Max. 300 V
Output energy: Max. 180 mJ
Test ports /
monitor voltage
Depending on device type (see Product Overvie
on page 15)
4.2.6 Interfaces
RS232
– VT100-Terminal
– Baud rate: 9,600, data bits: 8, stop bit: 1, parity: none
– Plug connection: D-SUB, 9-pole
– Maximum lead length: 5 m
4.2.7 Requirements for External Equipment
External equipment shall fulfill the input and output specifications of the MIC500.
