7.3 Remote-Controlled Ignition Release
No digital input at P/N 06.00.513
The device type P/N 06.00.513 is designed as a replacement for the ignition
controller Caterpillar® 163-6164. Thus, the device does not have the digital
input (Switch A/B, Switch Start/Stop) as described in this operating manual.
With this device type, schedule A settings are applied solely for ignition
timing configuration.
Via the digital input, the ignition of the MIC500 ignition controller can be switched on and off by
a master control.
In order to use this function, the digital input must be set to the function Switch Start/Stop. In
this mode, the ignition controller applies solely the settings from schedule A. If the digital input
is closed, the ignition of the ignition controller is switched off.
A security speed can be specified, above which the ignition after a switch-off cannot be activated
until the engine is at a standstill.
For the configuration of the digital input, see section Select Function for Digital Input on page 87.
For the configuration of the security speed, see section Set Security Speed on page 85.
