Save each parameter separately
The values that you change for control are not taken over by the ignition
controller until you have saved the changes. Therefore, save each individual
parameter change with [F5].
5. Save the parameter change with [F5]. The data is not applied by the ignition controller for
control until it has been saved.
6. To change additional parameters, return to step 1.
Leaving Parameterization Level
To leave the parameterization level and return to the main view, proceed as follows:
1. From the configuration view of a parameter, press the [Esc] key to return to parameter view.
If you have changed the respective parameter, the change will only be saved if you press
[F5] prior to exiting.
2. From the parameter view, press [Esc] to return to the main view.
The MIC500 ignition controller exits the programming mode and is ready for operation
(LED flashes briefly every 2 seconds).
Using the Help Function
Via the help function, further information is available for every shown parameter.
– You can access help information for the displayed parameter by pressing [F4].
– You can jump between the help texts by pressing [F2] to jump a step ahead, and [F3] to jump
a step back.
– You can exit the Help menu by pressing [Esc].
This returns you to parameter view.
