No. Parameter Function Configuration
9 SPEED CURVE A Activate or deactivate the speed curve
for schedule A
see Activate
Functions for
Schedules A and B
on page 89
10 4-20 A 4-20 mA input for activating or
deactivating schedule A
11 SPEED CURVE B Activate or deactivate the speed curve
for schedule B
12 4-20 B 4-20 mA input for activating or
deactivating schedule B
13 POT CCW Maximum potentiometer angle BTDC
with left rotating direction
see Set Potentio-
meter Limits on
page 91
14 POT CW Minimum potentiometer angle BTDC
with right rotating direction
15 MAX ADV A Earliest permissible ignition timing for
schedule A
see Set Ignition
Timing Limits on
page 93
16 MAX RET A Latest permissible ignition timing for
schedule A
17 MAX ADV B* Earliest permissible ignition timing for
schedule B
18 MAX RET B* Latest permissible ignition timing for
schedule B
19 B OFFSET* Timing offset for schedule B see Set Timing
Offset for Schedule
B on page 95
20 4mA TIMING* Ignition timing adjustment via the
analog signal at 4 mA
see Set Limits for
4-20 mA Input on
page 95
21 20mA TIMING* Ignition timing adjustment via the
analog signal at 20 mA
22 DFLT 4-20* Ignition timing adjustment in the event
of signal loss at the 4-20 mA input
23 # SPEED POINTS* Number of speed points for the speed
curve (max. 5 points)
see Set Speed
Curve on page 97
24 BP1* to BP5* Definition of the speed value and the
ignition timing adjustment for the
individual speed curve speed points BP1
to BP5
