Rev. 01/2015 55
One revolution of the pickup changes the distance as follows:
Thread Change in distance
M12x1 1 revolution ≙ 1 mm (0.04'')
5/8"-18 UNF 1 revolution ≙ 1.41 mm (0.05'')
3/4"-16 UNF 1 revolution ≙ 1.59 mm (0.06'')
For problems with the pickup signal, see section Pickup Input Errors on page 112.
Auxiliary pickup supply voltage
Depending on the device type, the terminal PU Power provides an auxiliary
supply voltage of 8 V DC or 24 V DC for the pickup. You will find an overview
in the section Product Overview on page 15.
Triggering information
Observe the following when configuring the triggering:
– The maximum tightening torque for the counter nut is 15 Nm (11 lb-ft) for
all pickups.
– Ensure that the pickup fits the respective triggering:
Pickup Type of triggering
Magnetic Holes, pins, screws, teeth, slots
Inductive Pins, screws, slots, holes (as of 8 mm
diameter)
Hall effect Magnets
