Moxa Technologies NPort 5600-8-DT Series User Manual

NPort 5600-8-DT/DTL Series IP Report Protocol
C-2
Hardware and AP ID
Each model is assigned a Hardware ID and AP ID as shown below:
Hardware ID AP ID Product
0x5700 0x80015610 5610-8-DT
0x5702 0x80015610 5650-8-DT
0x5703 0x80015610 5650I-8-DT
0x5704 0x80015610 5610-8-DT-J
0x5706 0x80015610 5650-8-DT-J
0x5710 0x80025610 5610-8-DTL
0x5711 0x80025610 5650-8-DTL
0x5712 0x80025610 5650I-8-DTL
Example
The following example shows the first 22 bytes of a typical IP address report:
report header
“Moxa”
item ID
item length
server name
“TEST”
item ID
item length
hardwa
re ID
0x516
item ID
item length
MAC address
00-90-E8-01-02-03
HEX
4D 4F 58 41 01 04 54 45 53 54 02 02 16 05 03 06 00 90 E8 01 02 03
ASCII
“M” “O” “X” “A” “T” “E” “S” “T”
