NPort 5600-8-DT/DTL Series Operation Mode Advanced Settings
Other Parameters
Local TCP port
Range: 1 to 65535
Default: 4001 for port 1, 4002 for port 2, etc.
Description: This specifies the TCP port number for communication to the
attached device. Socket applications will need to refer to the device using
this port number. For Pair Connection modes, this field specifies the
slave’s port number, and the same value must be used for the master’s
Destination IP parameter.
Command port
UDP Mode
Range: 1 to 65535
Default: 966
Description: This specifies the TCP port number for Moxa IP-Serial Library
commands. You do not need to reference this port number in your
application when using the Moxa IP-Serial Library, since the library
automatically obtains the number from the device server. Change this
setting only if there is a port number conflict with another application or
device.
Destination IP address
UDP Mode
Range: N/A
Default: none
Description: This specifies the IP address for the slave end of a pair
connection.
Destination IP address 1 through 4
UDP Mode
Range: N/A
Default: none
Description: This specifies the network host(s) that will access the
device. Serial data will be transmitted to every address listed, and
network data will be sent to the device on a first-in-first-out basis.
Designated local port 1 through 4
UDP Mode
Range: 1 to 65535
Default: none
Description: This specifies the TCP port number that will be used for data
transmission with the device port.
