NPort 5600-8-DT/DTL Series Operation Mode Advanced Settings
Local listen port
UDP Mode
Range: 1 to 65535
Default: 4001 for port 1, 4002 for port 2, etc.
Description: This specifies the UDP port number for network
communication to the serial device. Socket applications will need to refer
to the device using this port number.
Connection Control
UDP Mode
Range: Startup/None, Any Character/None, Any Character/Inactivity
Time, DSR On/DSR Off, DSR On/None, DCD On/DCD Off, DCD On/None
Default: Startup/None
Description: This specifies how connections to the device are established
and closed.
For example, “Startup/None” means that as soon as the device server
starts up, the TCP connection is opened,
and the connection can only be
closed manually. “DCD On/DCD Off” means that the TCP connection is
opened when the DCD signal is on, and closed when the DCD signal is off.
If you want to use the Inactivity Time parameter to close the connection
when the serial device is inactive, you must set Connection Control to
“Any Character/Inactivity time”.
Map <CR-LF>
Range: CR, LF, or CR-LF
Default: CR-LF
Description: This specifies how the ENTER key is mapped from the
Ethernet port through the serial port. For certain terminal applications,
the Enter key needs to be translated specifically as a CR character rather
than CR-LF.
