NPort 5600-8-DT/DTL Series Operation Mode Advanced Settings
Max connection
UDP Mode
Range: 1 to 4
Default: 1
Description: This specifies the maximum number of simultaneous
connections that the port will accept. When adjusting Max connection,
make sure that Ignore jammed IP and Allow driver control are also
adjusted correctly.
Ignore jammed IP
Range: Yes or No
Default: No
Description: This field specifies how an unresponsive IP address is
handled when there are simultaneous connections to the device port (see
Max connection). “Yes” means that transmission to the other hosts will
not be suspended if one IP address becomes un
that all transmission will be suspended if one IP address becomes
unresponsive, and will resume when all hosts have responded. “Yes” is
the recommended setting when Max connection is 2 or more.
Allow driver control
UDP Mode
Range: Yes or No
Default: No
Description: This specifies whether the device port will respond to driver
control commands when multiple simultaneous connections are enabled
(see Max connection).
Data Packing Parameters
Packing length
Range: 0 to 1024
Default: 0
Description: This controls data packing by the amount of data received.
Serial data accumulates in the device port’s buffer until it reaches the
specified length. When the specified amount of data has accumulated in
the buffer, the data is packed for network transmission. A setting of 0
means that data will not be packed until the buffer is full. 0 is the
recommended setting, unless your application has a specific need to limit
packet sizes or improve response times.
