9 Operation
Maschinenfabrik Reinhausen GmbH 2022108 8595028/00 ENTAPCON
®
250
Property Options
Decimal places
1)
Set up to three decimal places.
Minimum/maximum
value
Set the minimum and maximum values of the sensor, e.g.
with a 4...20mA signal, the corresponding measured
value for 4mA and the corresponding value for 20mA.
Correction factor
2)
Set the correction factor (m) for the correction of the func-
tion value (x). The corrected function value (y) is:
y=(m*x)+t
Correction offset
2)
Set the offset (t) for the correction of the function value
(x). The corrected function value (y) is: y=(m*x)+t
Table22: Configuration of the analog inputs and outputs
1)
Only available for AIO.
2)
Only available for inputs.
You can only change the configuration of the analog inputs if you have a
Parameter Configurator or Administrator role.
When in delivery status, you can log in as the administrator as follows:
▪ User name: admin
▪ Password: admin
Creating a backup
You need to create a backup to be able to reset the system in the event that
any incorrect configuration settings are made.
1. Go to Settings > Export.
2. Go to the option Settings to export a backup copy of the current settings.
3. Select the desired interface.
4. Press the Export button to start the export.
Configuring AIO
1. Go to Settings > AIO configuration.
2. Configure properties such as function, signal type and card/channel.
3. Select the button to configure the values as desired.
4. Press the Accept button.
5. Confirm the security prompt with Save to save the changes.
