MR TAPCON 250 - Power Supply PS; G1 Power Supply

13 Technical data
Maschinenfabrik Reinhausen GmbH 2022 1878595028/00 EN TAPCON
®
250
Interface Pin Description
1 Power supply (+)
2 Not used
3 Not used
4 Power supply (-)
Table66: Terminal X1
Interface Pin Description
1 TxD+
2 TxD-
3 RxD+
4 NC
5 NC
6 RxD-
7 NC
8 NC-
Table67: Jacks X2, X3 (Ethernet)
13.2.4 Power supply PS
8620
Permissible voltage range 18...78V DC
U
N
: 24...60V DC
Permissible frequency range -
Nominal power consumption 19.2W
Power output 12W
Table68: PS assembly technical data
13.2.5 G1 power supply
G1
Permissible voltage range 90...264 VAC
Permissible frequency range 47...63 Hz
Maximum inrush current impulse 60 A
Table69: Power supply
