MR TAPCON 250 - Connections and fuses

4 Product description
Maschinenfabrik Reinhausen GmbH 2022 378595028/00 EN TAPCON
®
250
4.4.4 Connections and fuses
The connections are located on the rear of the device. You will find more in-
formation on the connections in the Technical data [►Section 13, Page 180]
section.
Figure23: Rear
1 WEB panel Ethernet M12 2 WEB panel USB
3 Customer connection 4 Strain relief
5 Grounding screw 6 Ethernet service port
