4 Product description
Maschinenfabrik Reinhausen GmbH 202222 8595028/00 ENTAPCON
®
250
4 Product description
4.1 Scope of delivery
Check the shipment for completeness based on the shipping documents.
▪ Automatic voltage regulator
▪ RJ45 Ethernet patch cable
▪ RJ45/M12 Ethernet patch cable
▪ Cap rail assemblies including connection plug for front plate
▪ Front plate including connection socket
▪ Additional nameplate
Device-type dependent
▪ CAN assembly including RJ45 Ethernet patch cable
▪ Interface module for Ethernet RJ45 to RS232/RS485
▪ Coupling module CI-8530 including RJ45 Ethernet patch cable
Optional
▪ Serial to FO converter (CM-0847)
▪ Ethernet to FO converter (MC2-2)
▪ Auxiliary current transformer MR-169 ACT
▪ Extension cable 3m between cap rail assemblies and front plate
▪ Shield connection terminal(s)
4.2 Function description of the voltage regulation
The device keeps the output voltage of a transformer with an on-load tap-
changer constant.
The device compares the transformer's measured voltage (U
actual
) with a de-
fined reference voltage (U
desired
). The difference between U
actual
and U
desired
is
the control deviation dU.
The device parameters can be adjusted to the line voltage behavior to
achieve a balanced control response with the on-load tap-changer only per-
forming a small number of tap-change operations.
