MR TAPCON 250 User Manual

13 Technical data
Maschinenfabrik Reinhausen GmbH 2022180 8595028/00 ENTAPCON
®
250
13 Technical data
13.1 TC250 technical data
13.1.1 Display elements
Display 5″ TFT colour display
LEDs 3 LEDs for operation display and messages
▪ POWER, AVR STATUS, ALARM
13.1.2 Materials
Front Aluminum, plastic
13.1.3 Dimensions
Front panel display:
W x H x D
161.9 mm x 419.1 mm x 2.3 mm
Mating connector: 20mm
Cap rail assemblies (dimensions without cap rail)
Single-row W x H x D Basic: 340mm x 124mm x 124mm
Pro/Expert: 455mm x 124mm x 124mm
Two-row W x H x D
Row1/row2
Basic: 200/100mm x 124mm x 124mm
Pro/Expert: 290/200mm x 124mm x 124mm
13.1.4 Voltage supply
Power supply
Permissible voltage range 85...150VAC
88...150V DC
U
N
: 100...140V AC
U
N
: 100...150V DC
Max. nominal power consumption 25W
Permissible frequency range 50/60Hz
Overvoltage category OC III
Surge test voltage 4kV, 1.2µs/50µs
External fuse Type: 3AG (fast-acting)
Rated voltage: 250V
Rated current: 2.5A
Table56: Power supply
