MR TAPCON 250 - Electromagnetic compatibility

6 Mounting
Maschinenfabrik Reinhausen GmbH 2022 578595028/00 EN TAPCON
®
250
Excessive line capacitance can prevent the relay contacts from interrupting
the contact current. In control circuits operated with alternating current, take
into account the effect of the line capacitance of long control cables on the
function of the relay contacts.
If you want to route Ethernet connections from a control cabinet or building,
we recommend using fiber-optic cables (in accordance with the
IEC61850-90-4 recommendation).
Cable Interface Cable type Conductor cross-sec-
tion
Max. length
Power supply (external) X9 Unshielded 2.5 mm²
Voltage measurement UI-X7 Shielded 2.5mm²
Current measurement UI-X7 Unshielded 4mm²
Digital signal inputs
110VAC
DI8 Shielded 1.5mm² 400 m (<25 Ω/km)
Digital signal inputs
24V DC
DI8 Shielded 1.5mm² 400 m (<25 Ω/km)
Auxiliary voltage output
24V DC
DI8 Shielded 1.5mm² 400 m (<25 Ω/km)
Digital signal outputs DO8 Shielded 1.5mm²
Analog signal inputs AI4 Shielded 1 mm² 400 m (<25 Ω/km)
Analog signal outputs AO4 Shielded 1 mm² 400 m (<25 Ω/km)
RS232, D-SUB 9-pole X3 Shielded 0.25mm² 25 m
RS485 X5 Shielded 0.25mm² 140m
CAN bus COM-X6 Shielded 0.75mm² 2000m (total CAN bus)
Ethernet RJ45 COM-X6 Min. CAT5, shielded
S/FTP
100m
Ethernet FO COM X4 Duplex LC multi-
mode, Om3, 1310nm
2000m
RJ45 patch cables Min. CAT5, shielded
S/FTP
approx. 30cm
Ground connection PE terminal Unshielded 6mm²
Table10: Recommendation for connection cables
6.4.2 Electromagnetic compatibility
The device has been developed in accordance with applicable EMC stan-
dards. The following points must be noted in order to maintain the EMC
standards.
