To export the events, proceed as follows:
ü First connect via PC.
1. Click on the Export button.
2. Select the desired option for data transmission.
ð The data is exported.
9.1.12 User administration
User administration is based on a system of roles. You must assign a role to
every user. You can define access rights to parameters and events for each
role.
9.1.13 Hardware
Under Hardware, you can display information about the device's hardware.
You will find information about the signal level of the individual channels for
the assemblies.
1. Go to Information > System > Hardware.
2. Select the desired Assembly in order to display the signal levels of the
channels.
9.1.14 Software
Under Software, you can display the version status of the software compo-
nents of the device.
► Go to Information > System > Software.
9.1.15 Import/export manager
The device is equipped with an import/export manager which can be used to
transmit data using a PC via the web-based visualization system.
9.1.15.1 Exporting data
You can export the following data from the device:
Option Description
System image Complete image of the system (software and configuration). If
you are using the option "with history", all of the event memory
entries are also exported.
System configu-
ration
System configuration
Event log All event memory entries.
Recorder Measured value memory export.
