13 Technical data
Maschinenfabrik Reinhausen GmbH 2022184 8595028/00 ENTAPCON
®
250
13.2 ISM® assemblies technical data
13.2.1 System networking COM-ETH
COM-ETH
Interfaces 5x Ethernet via RJ45
RJ45 Max. 100m (per section)
10/100Mbps
Redundancy protocols HSR, PRP, RSTP
Table59: COM-ETH assembly technical data
Interface Pin Description
1 TxD+
2 TxD-
3 RxD+
4 NC
5 NC
6 RxD-
7 NC
8 NC-
Table60: Connectors X1…X5 (Ethernet)
13.2.2 Central processing unit
Processor ARM Cortex A9 processor 800MHz
RAM 512MB
NVRAM (SRAM with battery
backup)
256kB
Application memory 2GB
Digital relay outputs 2; galvanically isolated
Nominal voltage DC 24/48/60V
Max. continuous current 1A (ohmic load)
Max. switching capacity 30W
Rated impulse voltage 2.0kV
