MR TAPCON 250 - ISM assemblies

4 Product description
Maschinenfabrik Reinhausen GmbH 202228 8595028/00 ENTAPCON
®
250
4 LED Event Red Illuminates as soon as a red event is
present.
Yellow Illuminates as soon as a yellow event
is present.
Blue Illuminates if there are no events or a
gray event is present.
4.4.3 ISM® assemblies
Figure7: Cap rail with assemblies (single-row installation)
1 Mains unit G1 2 Communication interfaces CI
3 CPU 4 Power supply PS
5 AO4 6 U3
7 I3 8 AI4
9 DI 16-24V 10 DI 16-110V
11 DO8 12 CAN module
13 RJ45 interface module
