MR TAPCON 250 - Ambient conditions; Standards and directives

13 Technical data
Maschinenfabrik Reinhausen GmbH 2022182 8595028/00 ENTAPCON
®
250
Overload capacity short-term 120A/1s (directly on the test tap of the measure-
ment card)
Surge test voltage 4kV, measurement category III
13.1.6 Ambient conditions
Operating temperature -25...+70°C
Storage temperature -30...+85°C
Relative humidity 5...95%, condensation not permitted
Maximum installation alti-
tude
<3,000m above mean sea level
Minimum clearance to
other devices / control
cabinet
Cap rail modules:
Above/below: 30mm (3.5in; equivalent to 2RU), behind
30mm (1.2in)
Left/right: 30mm
WEB panel:
Rear 30mm (1.2in)
Contamination level 2
Protection class 1 (protective conductor connection)
Table58: Permissible ambient conditions
13.1.7 Standards and directives
Electromagnetic compatibility IEC61000-6-2; IEC61000-6-4;
IEC61000-6-5;
KS C 9610-6-2; KS C 9610-6-4
FCC47 CFR Part 15 B
Radiocommunication Act – IECS-003
Electrical safety IEC 61010-1; UL 61010-1; CSA-C22.2
No. 61010-1
IEEE CB scheme procedure
Climatic ambient conditions IEC60068-2-1 (-25°C; 96h) cold
IEC60068-2-2 (+70°C; 96h) dry heat
IEC60068-2-78 (+40°C / 93% rH, 96h)
moist heat, constant
IEC60068-2-30 (+55°C, 6 cycles 12 +
12hours) moist heat, cyclical
Degree of protection IP20
Environmental durability tests
