13 Technical data
Maschinenfabrik Reinhausen GmbH 2022186 8595028/00 ENTAPCON
®
250
Interface X4 Pin Description
8 NC
7 NC
6 GND
5 NC
4 NC
3 NC
2 TXD+/RXD+
1 TXD-/RXD-
Table63: Serial interface RS485 CPU:X4
Interface X5 Pin Description
8 DTR (O)
7 DCD (I)
6 GND
5 RXD (I)
4 TXD (O)
3 VCC/OUT
5V/12V
2 RTS (O)
1 CTS (I)
Table64: Serial interface RS232 CPU:X5
13.2.3 System networking BES
BES
Interfaces 2x Ethernet via RJ45
RJ45 Max. 100m (per section)
10/100Mbps
Input voltage 18…78VDC
U
N
24…60VDC
Input current 0.6/0.3/0.25A (24/48/60VDC)
Table65: BES assembly technical data
