MR TAPCON 250 - Page 197

13 Technical data
Maschinenfabrik Reinhausen GmbH 2022 1978595028/00 EN TAPCON
®
250
Interface Pin Description
1
2
3
4
5
6
7
8
9
10
10 Not used
9 Voltage input phase 1
8 Voltage input neutral conductor 1
7 Voltage input phase 2
6 Voltage input neutral conductor 3
5 Voltage input phase 3
4 Voltage input neutral conductor 3
3 Not used
2 Voltage input phase 4
1 Voltage input neutral conductor 4
Table95: Connector X2
13.2.13 System networking MC2-2
MC 2-2
Description Media converter
Interfaces 2x RJ45
2x duplex LC (SFP)
RJ45 Max. 100m (per section)
10/100 Mbit/s
Cable impedance 100Ω
Fiber-optic cable Max. 2,000 m
100 Mbit/s
Light-emitting diode: class 1
Wave length: 1310nm
Max. optical output power: <1 mW (in accordance
with IEC 60825-1:2014)
Table96: Technical data for the MC 2-2 assembly
