9 Operation
Maschinenfabrik Reinhausen GmbH 202292 8595028/00 ENTAPCON
®
250
9.1.6.2 Configuring IEC60870-5-101
If you want to use the IEC60870-5-101 control system protocol, you must
set the following parameters.
1. Go to Settings > Parameters > System > IEC60870-5-101.
2. Select the desired parameter.
3. Set the parameter.
4. Press the Accept button to save the modified parameter.
Serial interface
You can use this parameter to select the serial interface for data transmis-
sion. You can select the following options:
▪ RS232
▪ RS485
Baud rate
You can use this parameter to set the serial interface's baud rate. You can
select the following options:
▪ 9600 baud
▪ 19200 baud
▪ 38400 baud
▪ 57600 baud
▪ 115200 baud
Number of link address octets
You can use this parameter to set how many octets are provided for the link
address.
Link address
You can use this parameter to set the link address.
Number of ASDU address octets
You can use this parameter to set how many octets are provided for the
ASDU address.
ASDU address
You can use this parameter to set the address of the ASDU.
