© Munters AB, 2020 79
CAUTION When delivering feed via an external batch bin, no silo data (invetory) is
provided.
11.4.2
E
LECTRONIC
B
ATCH
W
EIGHING
I
NSTALLATION
Batch weigher load cells measure the quantties of the feeds placed into the bin. The batch
weight is measured during the filling process to ensure accurate ingredient weight data.
Over time, Trio learns how much time is needed between transmitting the stop signal and
actually stopping the augers.
After filling the batch bin, Trio releases a valve, emptying the feed into the batch hoppers.
The mixing process continues until the hopper is filled and a signal is sent.
As an option the batch quantity can be delivered in cycles (improving the ingredient
mixing).
Wiring and Mapping
Batch Bin Calibration
Configuration
Dashboard
Pausing Batching Mixing and Feed Mixing
11.4.2.1
Wiring and Mapping
Map and define cross augers (refer to Error! Reference source not found., page Error!
Bookmark not defined.).
1. In System > Devices and Sensors > Installation > Scale, designate one scale port as
Batch Weigher.
2. Define:
o
Bin Capacity: Define the batch bin’s capacity. Go to Defining the Time/Date,
page 12 to define the units as imperial or metric. This parameter is used to
