Muton XPJ-1641SR - Checking ink and replacing ink bag

Checking ink level 111
3 Chec king ink and repla cing ink b ag
• 4-color setting (XPJ-1641SR)
• 4-color setting (XPJ-1682SR)
• 7-color setting (XPJ-1682SR)
Checking ink level
[1]
Tap [Home].
[2]
Tap .
[3]
Tap until the menu on the left appears.
•Tap .
[4]
The ink level is displayed from 0% to 100%.
Note
• The left is an example when using XPJ-1682SR.
• To identify the ink slots corresponding to the numbers shown here, see
"Main
components of your printer" P. 9.
K
Black C Cyan M Magenta Y Yellow
1 K1 (Black) 2 K2 (Black) 3 C1 (Cyan) 4 C2 (Cyan)
5 M1 (Magenta) 6 M2 (Magenta) 7 Y1 (Yellow) 8 Y2 (Yellow)
1 M (Magenta) 2 Lm (Light Magenta) 3 C (Cyan) 4 Lc (Light Cyan)
5 K (Black) 6 Cl (Cleaner) 7 Y (Yellow) 8 Lk (Light Black)
Checking ink and replacing ink bag
Menu 1
Setup
Setup 16
Ink Status
1 2 3 4 : 100 / 90 / 90 / 80
5 6 7 8 : 100 / 90 / 90 / 80
