96 Test Print 5: Adjust Head (XPJ-1682SR Only)
When “Adjust Head 2 Custom” is selected
Standard or Custom Adjustment Methods
1. Print the Head adjustment pattern and look for a place in the pattern that has least white lines or overlapping
images.
•If you selected “Adjust Head 2: Custom”, select “ALL” or “A” to “F”.
•The number printed under the pattern without alignment errors is the adjustment value.
2. Enter the adjustment value.
You can select the adjustment method.Tap to open the submenu.
When selecting “Fine Pattern X (A to F)”, select the option that corresponds to the
print mode used for printing.
If the resolution, pass and the printing direction of the RIP print mode differ from
the print mode for the User Type, select the fine pattern that is suitable for the
RIP.
"Adjustment patterns for each print mode (XPJ-1682SR)" P. 65
Submenus
Adjusts all the patterns.
For printing an adjust pattern selected
from A to F.
Note
• Warm up the heater before printing the Adjustment pattern.
“Skip Heater Warm Up? No” is displayed on the front panel.
• You can start printing while the printer is warming up.
"Starting printing during warming up" P. 45
While “Warming Up” is displayed, do not touch Media guide.
You could burn yourself.
Custom 1
Fine Pattern ALL
・
・
・
Custom 2
Fine Pattern A
Custom 7
Fine Pattern F
To Next Page
