130 ◆ Section 4: Specifications and Parts List DS1000/2000 Product Description
Cabling Requirements
• Do not run station cable parallel with the AC source, telex or computer, etc. If the
cables are near cable runs to those devices, use shielded cable with grounded
shields or install the cable in conduit.
• When cables must be run on the floor, use cable protectors.
• Cable runs for key telephones, single line telephones and Door Boxes must be a
dedicated, isolated cable pair.
Device: Cable Type: Cable Run
Length (ft.):
Notes:
DS2000 Cabling Requirements
Key Telephone 2-wire 26 AWG
2-wire 24 AWG
1300
2000
Single Line
Telephone
2-wire 26 AWG 11,500 at constant 20 mA
3150 at constant 35 mA
2-wire 24 AWG 18,000 at constant 20 mA
5050 at constant 35 mA
2-wire 22 AWG 29,000 at constant 20 mA
8000 at constant 35 mA
2-OPX Module 2-wire 24 AWG 1000
DS1000 Cabling Requirements
Key Telephone 2-wire 26 AWG
2-wire 24 AWG
650
1000
Single Line
Telephone
2-wire 26 AWG 8000 at constant 20 mA
2-wire 24 AWG 12,000 at constant 20 mA
2-wire 22 AWG 16,000 at constant 20 mA
Analog Door Box
(DS1000 Only)
2-wire 24 AWG
2-wire 22 AWG
330
550
2-OPX Module 2-wire 24 AWG 1000
