Section 2: Components
16 ◆ Section 2: Components DS1000/2000 Product Description
UltraMail
UltraMail and UltraMail 2000
UltraMail and UltraMail 2000 are PCB-based, digitally-linked, “in-skin”
Voice Mail with Automated Attendant systems for DS2000. UltraMail uses
flash memory storage and provides up to 8 voice mail ports, 200 mailboxes,
and 3 hours of message storage. UltraMail 2000 is hard disk based and pro-
vides up to 8 voice mail ports, 1000 mailboxes, and at least 130 hours of
message storage.
Make a note of the following…
● For additional information on the UltraMail and UltraMail 2000, refer
to the Aspire Mail and UltraMail System Guide (P/N 17710SWG**).
✍ UltraMail and UltraMail 2000 components at a glance —
P/N 17712 UltraMail, 2 Port, 3 Hour, 200 Mailboxes (Flash memory based)
P/N 17714 UltraMail, 4 Port, 3 Hour, 200 Mailboxes (Flash memory based)
P/N 17744 UltraMail 2000, 4 Port, 130 Hour minimum, 1000 Mailboxes
(Hard disk based)
P/N 0891044 UltraMail 2 Port to 4 Port Software Upgrade
P/N 0891045 UltraMail 4 Port Expansion PCB for UltraMail P/Ns 17712 and 17714.
P/N 0891034 UltraMail 2000 4 Port Expansion PCB for UltraMail 2000 P/N 17744.
UltraMail and UltraMail 2000 Specifications
UltraMail UltraMail 2000
Ports 2 expandable to 8 4 expandable to 8
Mailboxes 200 1000
Storage Hours 3 Hours 130 Hours (Minimum)
Answer Schedule Tables 16
Dial Action Tables 100
Distribution Lists 100
Programming Interface Serial Port (using cable
P/N 80893 and adaptor
P/N 85980)
Serial Port, LAN con-
nection, or Modem
Mailbox
Remote Programming Access Customer-provided
modem connected to
serial port
LAN or Modem Mail-
box
