Section 2: Components
24 ◆ Section 2: Components DS1000/2000 Product Description
DS1000 System Configuration
DS1000 Default Hardware Configuration
Using the factory installed default configuration, your DS1000 system provides:
DS1000 Load Factor Calculations
The combination of extensions, 2-OPX Modules, and DSS Consoles you can connect to your sys-
tem may be limited by the System Load Factor. Use the DS1000 System Load Factor Calculations
chart on the next page to verify your system’s configuration.
To check your system configuration:
1. Indicate the quantity for each item installed in the Qty column.
2. For each item, multiply the Qty times the Load Factor and enter the value in Total Load.
3. Add all the values in the Total Load column and enter the value in Item 1.
4. Compare the entry in Item 2 to your entry in Item 1. Item 1 must always be equal to or less
than the entry in Item 2.
Base Expansion Total
Trunks 3 3 6
Digital Extensions 8 8 16
Analog Extensions 4 4 8
Analog Door Boxes 1 1 2
Relays 1 1 2
Page Output 1 1
Music Input 1 1
