Section 2: Components
DS1000/2000 Product Description Section 2: Components ◆ 25
2
Default Feature Configuration
This is how your system operates on initial power-up:
Trunks
In DS1000, trunks 1-6 (if installed) ring line keys 1-6 and single line telephones.
● Trunks 4-6 will only work if you have an Expansion Board installed.
In DS2000, trunks 1-12 ring on line keys 1-12 for extensions 300-315.
● All other extensions are lamp-only for trunks 1-12 on line keys 1-12.
● Trunks 13-64 do not appear on line keys.
● Single line sets do not ring for incoming trunk calls.
All trunks (outside lines) on ATRU PCBs are loop start DTMF.
● If you have Dial Pulse lines, you’ll have to reprogram the trunk circuit type. For T1 trunks, see
the Software Manual on your System Document CD.
Keysets
The circuit types for extensions are automatically set when the extension is plugged in.
Keyset users can place outside calls by pressing a line key and dialing the outside number.
●
In DS1000, all extension users can also place outside calls by dialing 9 plus the outside number.
At the attendant’s extension (300), key 11 is the Night Key and the last key on the phone (12 or 24 -
depending on telephone model) is the Operator Call Key.
● Pressing the Night Key puts the system in the night mode.
●
Use the Operator Call Key to answer incoming Intercom calls queued at the attendant’s extension.
!! Important !!
Do not operate your system if the System Load Factor total (Item 1)
exceeds the allowable load of 30 (Item 2).
DS1000 System Load Factor Calculations
Description Load Factor Qty Total Load
Digital Telephone 1
Analog Telephone 1
Analog Door Box 0
24-Button DSS Console 1
110-Button DSS Console 2
Total DSS Consoles installed cannot exceed 4
2-OPX Module 3
Item 1: Total load for this configuration
Item 2: Maximum allowable load 30
