5. RAID System Configuration
Express5800/T110f-S, R110f-1E, T110f-E Maintenance Guide
103
Chapter 2 Useful Features
5.2
Menu Tree
: Selection and execution parameter z: Setting parameter •: Data display
¡: Can be set or modified after a Virtual Drive is created
(1/2)
Menu Description
Configure Specify configuration settings
Easy Configuration Set a configuration using fixed values
New Configuration Set a new configuration
View/Add Configuration Add or view a configuration
Clear Configuration Clear the configuration data
Select Boot Drive Select a Virtual Drive to be booted
Initialize Initialize the Virtual Drive
Objects Set up various objects
Adapter Set up the RAID Controller
Sel. Adapter Select an adapter
zRebuild Rate 30
zChk Const Rate 30
zFGI Rate 30
zBGI Rate 30
zDisk WC Off
zRead Ahead On
zBios State Enable
zCont on Error Yes
zFast Init Enable
zAuto Rebuild On
zAuto Resume Enable
zDisk Coercion 1 GB
zFactory Default Reset to the default values
Virtual Drive Operate a Virtual Drive
Virtual Drives Select a Virtual Drive (when multiple Virtual Drives exist)
Initialize Initialize the Virtual Drive
Check Consistency Check Virtual Drive consistency
View/Update Parameters View the Virtual Drive information
• RAID View the RAID level
• SIZE View the Virtual Drive capacity
• Stripe SIZE View the stripe size
• #Stripes View the number of Hard Disk Drives in the Virtual Drive
• State View the Virtual Drive status
• Spans View the span setting
• Disk WC View the write cache setting
• Read Ahead View the read ahead setting
