5. RAID System Configuration
Express5800/T110f-S, R110f-1E, T110f-E Maintenance Guide
113
Chapter 2 Useful Features
5.3.4
Executing the Consistency Check
Run the LSI Software RAID Configuration Utility
Execute the Consistency Check
Exit the LSI Software RAID Configuration Utility
Important
Do not execute the Consistency Check for RAID0.
1. Run the LSI Software RAID Configuration Utility.
2. Choose Check Consistency from the TOP menu.
The Virtual Drives screen appears.
3. Move the cursor to the hard disk drive to be checked for consistency, and then press the space key to
select it. The virtual drive is selected.
4. Press <F10> key.
5. To start the Consistency Check, choose Yes at the confirmation message.
The Consistency Check completes when the "Completed" progress bar on the CC Under Progress
screen reaches 100%.
6. Press <Esc> key to return to the TOP menu screen, and then exit the LSI Software RAID Configuration
Utility.
