8. System Diagnostics
Express5800/T110f-S, R110f-1E, T110f-E Maintenance Guide
48
Chapter 1 Maintenance
8.
System Diagnostics
System Diagnostics run several tests on the server.
8.1
Test Items
The following items are tested in System Diagnostics.
• Memory
• CPU cache memory
• Hard disk drive
Important
Before executing the System Diagnostics, be sure to disconnect the LAN
cable. Executing the System Diagnostics with the LAN cable connected may
affect the network.
Tips
On checking the hard disk drives, no data is written to the disk.
8.2
Startup and Exit of System Diagnostics
Start up System Diagnostics in the following procedure. (If the server is running, shutdown the system.)
1. Start up EXPRESSBUILDER and select Tool menu from Boot Menu.
For information on starting up EXPRESSBUILDER, see Chapter 2 (6. Details of EXPRESSBUILDER).
Note In case Language selection menu appears, choose English.
If "Hit key to continue. [y|Y]" is displayed in Redirection mode, press <y> key (or
<Y> key).
2. Select Test and diagnostics.
3. Select End-User Mode (Basic) to start System Diagnostics. This process takes about three minutes.
When the diagnostics is completed, the screen changes as shown below.
See eupro_ug_en.pdf in the ¥isolinux¥diag folder of EXPRESSBUILDER for the End-User Mode
(Professional) feature.
To Next Page
