5. RAID System Configuration
Express5800/T110f-S, R110f-1E, T110f-E Maintenance Guide
117
Chapter 2 Useful Features
5.5
WebBIOS and Universal RAID Utility
The points to be noted when using the Universal RAID Utility together with the WebBIOS are described below.
(1) Terms
Some terms are different between the WebBIOS and Universal RAID Utility. When using the Universal RAID
Utility together with the WebBIOS, replace the terms as shown in the table below:
Terms of Universal RAID Utility
Terms of WebBIOS
RAID Viewer raidcmd
Adapter RAID Controller RAID Controller
Virtual Drive Logical Drive Logical Drive
Drive group Disk Array Disk Array
Drive Physical Device Physical Device
Tips
raidcmd is a command provided by the Universal RAID Utility. For details, refer
to "Universal RAID Utility User’s Guide".
(2) Numbering
The numbers indicating RAID Controller information differ between the WebBIOS and Universal RAID Utility as
shown in the table below.
For details about the differences, see "Universal RAID Utility User’s Guide".
Management Number Item
WebBIOS Universal RAID Utility
Adapter (RAID Controller) Starts from 0 Starts from 1
Virtual Drive (Logical Drive) Starts from 0 Starts from 1
Drive group (Disk Array) Starts from 0 Starts from 1
Drive (Physical Device) Starts from 0
To be assigned based on
an enclosure that contains
the physical device and its
slot number.
To Next Page
