3. Flash FDD
Express5800/T110f-S, R110f-1E, T110f-E Maintenance Guide
99
Chapter 2 Useful Features
3.
Flash FDD
Flash FDD is a device that is compatible with a floppy disk drive.
One Flash FDD can be connected to a USB connector of this server. If another USB or floppy disk drive is
connected to the server, remove it before using Flash FDD.
CAUTION
Be extremely careful not to lose the Flash FDD or have it stolen.
If the Flash FDD is lost, stolen, misappropriated, or fraudulently obtained, there is a risk
of leaking confidential information to a third party. NEC assumes no responsibility for
damages caused by leaking confidential information in this way.
If you want to change the write protection, remove Flash FDD from the server and change the write protection
switch, and then connect it again.
3.1
Precautions
Do not use Flash FDD to back up data. Flash FDD can be used to save temporary data.
3.1.1
Compensation for recorded data
NEC does not pay compensation for data recorded on Flash FDD even if the data is lost.
3.1.2
Handling Flash FDD
• Flash FDDs are consumables. If Flash FDD causes an error, exchange to a new Flash FDD.
• Do not turn off the server while the access LED of Flash FDD is blinking.
• Flash FDD cannot be connected to a USB hub. Directly connect Flash FDD to the server.
• Before touching Flash FDD, discharge static electricity from your body by touching a nearby metal object
such as a doorknob or aluminum frame.
• Do not disassemble Flash FDD.
• Do not place Flash FDD in an area directly exposed to sunlight or near a heater.
• Do not handle Flash FDD while eating, drinking, or smoking. Also, avoid contact with thinner, alcohol, or
other corrosive substances.
3.1.3
Precautions when using EXPRESSBUILDER
• Connect Flash FDD after Home Menu is displayed.
• When you close EXPRESSBUILDER, remove Flash FDD from the server.
To Next Page
