NETGEAR GS310TP User Manual

Configure Switching
103
S350 Series 8-Port Gigabit Ethernet Smart Managed Pro Switch Models GS308T and GS310TP
Configure the Port Settings and Maximum Frame Size
You can view, configure, and monitor the physical port information for the ports (that is, the
physical interfaces) on the switch.
 To configure the port settings and maximum frame size:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is of
f-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser
, enter the IP address of the switch.
If you do not know the IP address of the switch, see Change the Default IP Address of the
Switch on page 11.
Your web browser might display a security message, which you can ignore. For more
information, see Access the Local Browser Interface on page 19.
The login window opens.
4. Enter the switch’
s password in the Password field.
The default password is password.
The System Information page displays.
5. Select Switching > Ports > Port Configuration.
6. In the Frame Size field, specify the maximum Ethernet frame size that each interface can
support.
The frame size includes the Ethernet header, CRC, and payload. The range is 1522 to
10000.
The default maximum frame size is 1522.
7. Select the check box to the left of the Port column to specify the interface for which data is
to be displayed or configured.
To select an interface, you can also enter the interface number in the Go T
o Interface
field and click the Go button.
8. In the Description field, enter the description string to be attached to a port.
The string can be up to 64 characters in length.

NETGEAR GS310TP Specifications

General

Power connector	DC-in jack
SFP module slots quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
Output current	1.25 A
Output voltage	54 V
Power consumption (max)	69.3 W
MAC address table	8000 entries
Jumbo frames support	Yes
Total Power over Ethernet (PoE) budget	55 W
Memory type	DDR-SDRAM
Flash memory	32 MB
Internal memory	128 MB
Processor frequency	500 MHz
Mean time between failures (MTBF)	1081119 h
Switch type	Managed
Switch layer	L2
DHCP features	DHCP client
Authentication	Auto VLAN, Guest VLAN, MAC-based authentication, Port-based authentication, Web-based authentication
Authentication type	HWTACACS+, IEEE 802.1x
Security algorithms	802.1x RADIUS, EAP, HTTPS, SSL/TLS
Access Control List (ACL) IPv4 entries	100
Stackable	-
Product color	Black
Rack mounting	No
Number of fans	0 fan(s)
Number of VLANs	64
Networking standards	IEEE 802.1D, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3at, IEEE 802.3az, IEEE 802.3x
Virtual LAN features	Voice VLAN
Operating temperature (T-T)	0 - 40 °C
Number of multicast groups filtered	256
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	101 mm
Width	263 mm
Height	30 mm
Weight	610 g
