Page #241 background imageLoading...
Page #241 background image
Manage Device Security
241
S350 Series 8-Port Gigabit Ethernet Smart Managed Pro Switch Models GS308T and GS310TP
The following table describes the fields in the Port Security Violations table.
Table 53. Port Security Violations information
Field Description
Port The physical interface.
Last Violation MAC The source MAC address of the last packet that was discarded at a locked port.
VLAN ID The VLAN ID corresponding to the last MAC address violation.
Configure a Port Security Interface
A MAC address can be defined as allowed on a port by one of two methods: dynamically or
statically. Both methods can be concurrently when a port is locked.
Dynamic locking implements a first arrival mechanism for port security. You specify how
many addresses can be learned on the locked port. If the limit is not reached, a packet with
an unknown source MAC address is learned and forwarded normally. If the limit is reached,
no more addresses are learned on the port. Any packets with source MAC addresses that
were not already learned are dropped. You can effectively disable dynamic locking by setting
the number of allowable dynamic entries to zero.
Static locking allows you to specify a list of MAC addresses that are allowed on a port. The
behavior of packets is the same as for dynamic locking: only packets with an allowable
source MAC address can be forwarded.
To configure a port security interface:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is of
f-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser
, enter the IP address of the switch.
If you do not know the IP address of the switch, see Change the Default IP Address of the
Switch on page 11.
Your web browser might display a security message, which you can ignore. For more
information, see Access the Local Browser Interface on page 19.
The login window opens.
4. Enter the switch’
s password in the Password field.
The default password is password.
The System Information page displays.
5. Select Security > T
raffic Control > Port Security > Interface Configuration.

Table of Contents

Other manuals for NETGEAR GS310TP

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR GS310TP and is the answer not in the manual?

NETGEAR GS310TP Specifications

General IconGeneral
Power connectorDC-in jack
SFP module slots quantity2
Installed SFP modules quantity0
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity8
Output current1.25 A
Output voltage54 V
Power consumption (max)69.3 W
MAC address table8000 entries
Jumbo frames supportYes
Total Power over Ethernet (PoE) budget55 W
Memory typeDDR-SDRAM
Flash memory32 MB
Internal memory128 MB
Processor frequency500 MHz
Mean time between failures (MTBF)1081119 h
Switch typeManaged
Switch layerL2
DHCP featuresDHCP client
AuthenticationAuto VLAN, Guest VLAN, MAC-based authentication, Port-based authentication, Web-based authentication
Authentication typeHWTACACS+, IEEE 802.1x
Security algorithms802.1x RADIUS, EAP, HTTPS, SSL/TLS
Access Control List (ACL) IPv4 entries100
Stackable-
Product colorBlack
Rack mountingNo
Number of fans0 fan(s)
Number of VLANs64
Networking standardsIEEE 802.1D, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3at, IEEE 802.3az, IEEE 802.3x
Virtual LAN featuresVoice VLAN
Operating temperature (T-T)0 - 40 °C
Number of multicast groups filtered256
Harmonized System (HS) code85176990
Weight and Dimensions IconWeight and Dimensions
Depth101 mm
Width263 mm
Height30 mm
Weight610 g
