XPS Unified Programmer’s Manual
7.2.1.61 GPIOAnalogRangeConfigurationSet
Name
GPIOAnalogRangeConfigurationSet Sets GPIO DAC range configuration for
analog output(DAC).
Input tests
- Refer to section 7.1: “Input Tests Common to all XPS Functions”.
- Checks if the GPIO type is DAC: (-8)
Description
This API sets the DAC range value. Set values are:
Input value = 0 = > Disabled
Input value ≥12.0 V = > DAC range = 12.288 V
Input value ϵ [10.0 , 12.0] = >DAC range = 10 V
Input value ϵ [5.0 , 10.0] = >DAC range = 5 V
Prototype
int GPIOAnalogRangeConfigurationSet(
int SocketID,
char * GPIOName,
double DACRange
)
Input parameters
SocketID int Socket identifier gets by the
“TCP_ConnectToServer” function.
GPIOName char * GPIO name.
DACRange double DAC range value.
Output parameters
None.
Return (In addition to the results of “Input Tests Common to all XPS
Functions”)
0: No error.
-8: Wrong object type for this command.
EDH0373En1023 01/18 108
