XPS Unified Programmer’s Manual
7.2.1.347 TZPTPulseOutputSet
Name
TZPTPulseOutputSet – Sets the configuration of pulse generation of a PT trajectory.
Input tests
- Refer to section 7.1: “Input Tests Common to all XPS Functions”.
- Checks group type (must be a TZ group): (-8)
- Checks group name: (-19)
- Checks the pulse generation must not be in progress: (-22)
- Not available in this configuration (PrecisionPlatform firmware only): (-24)
Description
This function configures and activates the pulse generation of a PT trajectory. The pulse
generation is defined by a start element, an end element, and a time interval in seconds.
If a pulse generation is already activated on the selected PT trajectory then this function
returns -22 (“Not allowed action”) error.
Please note that the pulse output settings are automatically removed when the trajectory
is over. Hence, with the execution of every new trajectory, it is required to define the
pulse output settings again.
This capability allows output of pulses at constant time intervals on a PT trajectory. The
pulses are generated between the first and the last trajectory element. The minimum
possible time interval is CorrectorISRPeriod value (system.ref).
The trajectory pulses are generated on the following GPIO ouputs:
GPIO
signals
ISA XPS
controller
Example:
TZPTPulseOutputSet(Group1, 3, 5, 0.01)
One pulse will be generated every 10 ms between the start of the 3rd element and the
end of the 5th element.
Prototype
int TZPTPulseOutputSet(
int SocketID,
char GroupName[250],
int StartElement,
int EndElement,
double TimeInterval
)
503 EDH0373En1023 — 01/18
