XPS Unified Programmer’s Manual
7.2.1.62 GPIOAnalogSet
Name
GPIOAnalogSet – Sets one or several analog outputs (DAC).
Input tests
- Refer to section 7.1: “Input Tests Common to all XPS Functions”.
- Checks if the GPIO type is DAC: (-8)
- Checks input parameters number: (-17)
Description
Sets analog value array for DAC type of GPIO.
Prototype
int GPIOAnalogSet(
int SocketID,
int NbElements,
char * GPIONameList,
double * AnalogValueArray
)
Input parameters
SocketID int Socket identifier gets by the
“TCP_ConnectToServer” function.
NbElements int Number of analog GPIO to read.
GPIONameList char * List of analog GPIO names – separator is
comma.
AnalogGainValueArray double * Analog GPIO value array (DAC or ADC).
Output parameters
None.
Return (In addition to the results of “Input Tests Common to all XPS
Functions”)
• 0: No error.
• -8: Wrong object type for this command.
• -17: Not allowed action.
• -22: Not allowed action.
109 EDH0373En1023 — 01/18
