XPS Unified Programmer’s Manual
7.2.2.42 ZygoAmplitudeGet
Name
ZygoAmplitudeGetGets the reference channel status and measuring channel
amplitude.
Input tests
- Refer to section 7.1: “Input Tests Common to all XPS Functions”.
Description
Returns the reference channel status and the measuring channel amplitudes.
Prototype
int ZygoAmplitudeGet(
int SocketID,
int * ZygoReferenceSignalStatus,
int * Meas1Signal,
int * Meas2Signal
)
Input parameters
SocketID int Socket identifier gets by the
“TCP_ConnectToServer” function.
Output parameters
EthernetCommunicationStatus int * 1 = Connected, 0 = Not connected.
Meas1Signal int * Measure 1 Signal Strength (refer to ZMI 2402
Diagnostic ADC).
Meas2Signal int * Measure 2 Signal Strength (refer to ZMI 2402
Diagnostic ADC).
Return (In addition to the results of “Input Tests Common to all XPS
Functions”)
0: No error.
-1001: The controller is not connected to Zygo TCP server. Run
ZygoStartInterferometer API.
EDH0373En1023 01/18 640
