XPS Unified Programmer’s Manual
7.2.1.190 PositionerCompensationPostExcitationFrequencyNotchFilterSet
Name
PositionerCompensationPostExcitationFrequencyNotchFilterSetSets Notch filter
parameters from F3 compensation block.
Input tests
- Refer to section 7.1: “Input Tests Common to all XPS Functions”.
- Checks Notch Frequency number (1 to 10): (-17)
- Checks parameter values: (-17)
NotchFrequency
with CorrectorPeriod = 0.0001 s
(10 kHz) = >
NotchBandwidth
with CorrectorPeriod = 0.0001 s
(10 kHz) = >
NotchGain
Description
This function configures the parameters defined for selected Notch filter from the post
excitation compensation (F3 block) configured in the current corrector (Option0,
Option1 or Option2).
If the “NotchFrequency” value is NULL or the “NotchGain” value is NULL then the
notch filter is not activated.
Notch filter parameters:
NotchFrequency (Hertz).
NotchBandwidth (Hertz).
NotchGain.
Prototype
int PositionerCompensationPostExcitationFrequencyNotchFilterSet(
int SocketID,
char * PositionerName,
int NotchFrequencyNumber,
double NotchFrequency,
double NotchBandwith,
double NotchGain
)
[ ]
5000:0
