TFE-4RV-1 Company Confidential
Troubleshooting Nokia Customer Care
Page 6-6 Copyright © 2005 Nokia Corporation Issue 2.0 Mar/2005
Company Confidential
Test-Setups for Troubleshooting
The following test setups are defined for troubleshooting on TFE-4/RV-1.
• General Test Setup
• Flashing on POS level
• Flashing on RCC level
• Selftest
•BT Test
•ADC Readings
• Audio Testing
• Digital I/O
• SIM Test
• RF Alignment
• Repair jig MJ-1
• Call Test
• PPC’s
The following service tools are basically needed to perform the tests.
• PC with Phoenix
• PKD-1 in combination with FPS-8
• FLS-4S Flashdongle
• CA-1S Flashcable
• AD-2 Poweradapter with ACW-4 Powersupply
• Test SIM card/Network SIM card
• MJ-1 Module Jig
General Test Setup (Check Phone Information)
HW-setup
Connect the product specific Flash-cable (CA-1S) to the used dongle (e.g. FLS-4S) and to
the Display-Connector of TFE-4/RV-1 (see figure 1)
A power adapter AD-2 is necessary to supply 13.8V to the Radio Unit.
(ACW-4 is the power supply for AD-2 power adapter)
