Nokia 616 Service Manual

Nokia Customer Care General Information
Company Confidential TFE-4/RV-1
Issue 2.0 Mar/2005 Copyright © 2005 Nokia Corporation. Page 1-7
Company Confidential
Mechanical Characteristics
Electrical Characteristics
External Signals and Connections
Table 3: Mechanical Characteristics
Unit Type Code Dimensions (mm)
(W x H x D)
Weight
Engine Board Size TF4 43 x 126 x 9.2 ********
Junction Board Size TF5 98.6 x 128 x 15 ********
Radio Unit TFE-4/RV-1 140 x 106 x 41 305 g
Input Device CUW-3 56 x 35 x 24 16.7 g w/o cable
Display Unit XDW-1R
SU-11
79 x 64 x 44
73 x 57 x 30
NA
45.5 g w/o cable
Handsfree Speaker SP-2 86 x 85 x 60 238 g w/cable
Handsfree Microphone HFM-8 43 x 24 x 13 37 g w/cable
Table 4: Supply Voltage
Line
Symbol
Parameter Type Min. Typical /
Nominal
Max. Unit / Notes
VBAT Input from a car battery Power In 10.8
9
13.5 16
16
27
V DC (full functionality)
V DC (reduced functionality)
V DC (not working max DC)
1.5
1
A DC (working)
mA DC (sleep mode)
Table 5: Power Consumption
Condition Current
Active (call)
< 1.5 A
Standbye
< 300 mA
Off
< 1 mA
Table 6: List of external connectors
Connector Name Conn. Manufacturer NMP code / Notes
TFE-4, N610
GSM antenna connector X209 CONN_ANT_3412 SM ANT CONN RF FME 50R 400V 3GHZ
Display Unit connector X103 CON_SS_641010_NF_K Modular Jack 10POL 90deg UNSH
Car connector X104 Molex 43045-0421 Micro-Fit 3.0 2x2
Speaker connector X105 SMK LGY2501-0500E 3.5 mm jack
Microphone connector X106 SMK LGK2509-0600E 2.5 mm jack
Input device X107 CON_SS_641010_NF_K Modular Jack 10POL +K2 Key 1.5A 90deg
RV-1, N616
GSM antenna connector X101 IMS 3412.72.1610.001 Antenna connector FME
RS232 Interface X102 Stewart SS-641010-NF-K1 Modular connector RJ-45 K1
Display Unit connector X103 Stewart SS-641010-A-NF-RMK4 Modular connector RJ-45 RMK4
