Nokia Customer Care 2 - Parts List
Company Confidential TFE-4/RV-1
Issue 2.0 Mar/2005 Copyright © 2005 Nokia Corporation Page 2-21
Company Confidential
PWB Component differences for N616
Note: There are No components on bottom side of PWB.
V306 L 1 TRX2+RX4 UMH9N 50V 0.1A ~ ~ ~ SOT_363
V400 E 15 ZDIX4 TVS/ESD RSA6.1EN 6V1 ~ ~ ~ SOT323_5L
V401 N 15 MFETX2 UM6K1N N 30V 0.1A 7R SC-88 ~ ~ ~ UMT6
X103 B 15 MODULAR JACK 10POL 90DEG UNSH ~ ~ ~ CON_SS_641010_NF_K
X104 A 12 CONN WTB 2X2F P3 250V 5A 90DEG ~ ~ ~ MOLEX_43045_0421
X105 B 9 SM JACK 3.5MM 12V 1A WTH LOCKING ~ ~ ~ JACK_T_332866_2
X106 A 7 SM JACK 2.5MM 12V 1A WTH LOCKING ~ ~ ~ JACK_T_332866_1
X107 B 4 MOD JACK 10POL+K2 KEY 1.5A 90DEG ~ ~ ~ CON_SS_641010_NF_K
X110 O 2 SM CONN 2X14 SPRING B2B ~ ~ ~ CONN_58_9158_028_0
00_028S
X111 Q 20 SM CONN 2X4 SPRING B2B ~ ~ ~ CONN_58_9158_008_0
00_029S
X112 L 20 SM CONN 2X4 SPRING B2B ~ ~ ~ CONN_58_9158_008_0
00_029S
X209 B 22 SM ANT CONN RF FME 50R 400V 3GHZ ~ ~ ~ CONN_ANT_3412
X210 Q 23 SM CONN RF PLUG 50R 100V 2GHZ ~ ~ ~ CONN_IMS_3384
Item
Location
Grid ref.
Description and value Type
C110 Q 17 ELCAP 470U +-20% 6V3 0R025 11.2X10.5 470u_6V3 6.3V normal,-20%,20% ELCAP_SVP_F8
C111 Q 14 ELCAP 470U +-20% 6V3 0R025 11.2X10.5 470u_6V3 6.3V normal,-20%,20% ELCAP_SVP_F8
C119 I 7 EL. CAP. 20% 50V 100u 50V normal,-20%,20% Sanyo
R304 M 7 CHIPRES 0W06 10K F 10k ~ normal,-5%,5% 0402R
V113
Deleted from N616
Item
Location
Grid ref.
Description and value Type
