Nokia 616 Service Manual

TFE-4/RV-1 Company Confidential
2 - Parts List Nokia Customer Care
Page 2-4 Copyright © 2005 Nokia Corporation Issue 2.0 Mar/2005
Company Confidential
Assembly Parts List
Parts List for TF4 Module (EB)
PWB Components (tf4-07a)
Item Qty Description
I001 1 ‘A’ Cover
I002 1 Warranty Sealing label
I003 9 Screw 2.5 dia. x 20
I004 1 SIM Cover
I005 1 Spring SIM Connector (not illustrated)
I006 1 Engine Unit (TF4 Module (EB))
I007 1 Frame
I008 1 Data Cap
I009 2 Screw 3 dia. x 5 T10
I010 1 Junction Module (TF5 Module (JB))
I011 1 Heatsink
I012 1 ‘B’ Cover
I013 1 Type Label
Item
Location
Side, Grid ref
Description and value Type
A800 Top D 5 PA-SHIELD ASSY DMC02107 HDA13 ~ ~ ~ SHIELD_DMC02107
B200 Top P 3 CRYSTAL 32.768KHZ+-30PPM 9PF 32.768kHz ~ ~ CRYSTAL_CX_4V
B601 Top J 8 CRYSTAL 26.0MHZ+-8PPM CL=15.5 26MHz ~ ~ CRYSTAL_TSX_8A
C102 Top Y 5 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C104 Top T 5 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C105 Top Y 3 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C106 Top X 3 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C107 Top Y 4 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C108 Top Y 5 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C109 Top Y 6 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C110 Top T 2 Chipcap X7R 10% 50V 1n0 50V normal,-10%,10% 0402C
C118 Top V 5 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C119 Top W 6 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C120 Top W 6 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C121 Top W 7 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C122 Top Y 6 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C148 Top N 2 CHIPCAP X5R 1u0 6.3V normal,-10%,10% 0603C
C149 Top N 2 CHIPCAP X5R 1u0 6.3V normal,-10%,10% 0603C
