Nokia 616 Service Manual

Nokia Customer Care 2 - Parts List
Company Confidential TFE-4/RV-1
Issue 2.0 Mar/2005 Copyright © 2005 Nokia Corporation Page 2-5
Company Confidential
C150 Top W 5 CHIP ARRAY NP0 2x27p 25V normal,-10%,10% 0405_2_P0.65
C151 Top U 4 CHIP ARRAY NP0 2x27p 25V normal,-10%,10% 0405_2_P0.65
C153 Top U 3 CHIP ARRAY NP0 2x27p 25V normal,-10%,10% 0405_2_P0.65
C154 Top U 3 CHIP ARRAY X5R 2x100n 10V normal,-20%,20% 0405_2_P0.65_AVX
C156 Top U 3 CHIP ARRAY X5R 2x10n 16V normal,-10%,10% 0405_2_P0.65_AVX
C159 Top U 3 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C163 Top U 2 Chipcap 5% NP0 27p 50V normal,-5%,5% 0402C
C164 Top T 4 CHIP ARRAY X5R 2x100n 10V normal,-20%,20% 0405_2_P0.65_AVX
C165 Top U 3 CHIP ARRAY X5R 2x100n 10V normal,-20%,20% 0405_2_P0.65_AVX
C166 Top U 3 CHIP ARRAY X5R 2x33n 10V normal,-10%,10% 0405_2_P0.65_AVX
C167 Top V 3 Chipcap X7R 10% 50V 1n0 50V normal,-10%,10% 0402C
C172 Top V 3 Chipcap X7R 10% 50V 1n0 50V normal,-10%,10% 0402C
C182 Top P 3 CHIP ARRAY X5R 2x100n 10V normal,-20%,20% 0405_2_P0.65_AVX
C200 Top P 5 CHIPCAP X5R 100n 10V normal,-10%,10% 0402C
C201 Top R 5 CHIPCAP X5R 1u0 6.3V normal,-10%,10% 0603C
C202 Top R 5 Chipcap X7R 10n 16V normal,-10%,10% 0402C
C207 Top N 3 CHIPCAP X5R 1u0 6.3V normal,-10%,10% 0603C
C208 Top P 5 CHIPCAP X5R 1u0 6.3V normal,-10%,10% 0603C
C209 Top P 2 Chipcap +-0.25pF NP0 5p6 50V normal,-0.25pF,0.25pF 0402C
C210 Top P 3 Chipcap +-0.25pF NP0 5p6 50V normal,-0.25pF,0.25pF 0402C
C218 Top N 3 CHIPCAP X5R 100n 10V normal,-10%,10% 0402C
C220 Top N 3 Chipcap X7R 10n 16V normal,-10%,10% 0402C
C236 Top N 6 CHIPCAP X5R 100n 10V normal,-10%,10% 0402C
C237 Top N 6 CHIPCAP X5R 100n 10V normal,-10%,10% 0402C
C238 Top P 5 CHIPCAP X5R 100n 10V normal,-10%,10% 0402C
C239 Top O 3 CHIPCAP X5R 100n 10V normal,-10%,10% 0402C
C240 Top N 3 Chipcap X7R 10n 16V normal,-10%,10% 0402C
C241 Top O 2 Chipcap X7R 1n0 50V normal,-10%,10% 0402C
C242 Top N 3 Chipcap X7R 1n0 50V normal,-20%,20% 0402C
C260 Top Q 2 CHIPCAP X5R 1u0 6.3V normal,-10%,10% 0603C
C261 Top Q 2 CHIPCAP X5R 1u0 6.3V normal,-10%,10% 0603C
C262 Top R 2 CHIPCAP X5R 1u0 6.3V normal,-10%,10% 0603C
C263 Top R 2 CHIPCAP X5R 1u0 6.3V normal,-10%,10% 0603C
C264 Top Q 2 CHIPCAP X5R 1u0 6.3V normal,-10%,10% 0603C
C265 Top R 2 CHIPCAP X5R 1u0 6.3V normal,-10%,10% 0603C
C274 Top O 2 CHIPCAP X5R 1u0 6.3V normal,-10%,10% 0603C
C275 Top P 4 CHIPCAP X5R 1u0 6.3V normal,-10%,10% 0603C
C276 Top P 4 CHIPCAP X5R 1u0 6.3V normal,-10%,10% 0603C
C277 Top O 3 CHIPCAP X5R 1u0 6.3V normal,-10%,10% 0603C
C278 Top O 3 CHIPCAP X5R 1u0 6.3V normal,-10%,10% 0603C
Item
Location
Side, Grid ref
Description and value Type
