TFE-4/RV-1 Company Confidential
General Information Nokia Customer Care
Page 1-8 Copyright © 2005 Nokia Corporation. Issue 2.0 Mar/2005
Company Confidential
Environmental Conditions
The transceiver is not protected against ingress of water. The transceiver may be instantaneously sub-
jected to splashed or condensed water. Longer-term contact with water will cause permanent damage.
Vibration
Temperature
Car connector X104 Molex 43045-0421 Micro-Fit 3.0 2x2
Speaker connector X105 SMK LGY2501-0500E 3.5 mm jack
Microphone connector X106 SMK LGK2509-0600E 2.5 mm jack
Input device, Handset
and Headset connector
X107 Stewart SS-641010-NF-K2 Modular connector RJ-45 K2
Table 7: Temperature ranges
Parameter Requirement Test Reference Duration Acceptance
Criteria
Vibration
(random)
Operational
10Hz-7m
2
/s
3
50Hz-3,5m
2
/s
3
60Hz-1,75m
2
/s
3
1000Hz-0,06m
2
/s
3
combined with gradual
change of temperature
1 cycle during 8h
DIN 72300-3 (draft)
Env.Hdbk. 4A: Climatic
and Mechanics
IEC 68-2-64
8h/axis Normal
Performance
or Reduced
performance
Bump
Operational
halfsine
6ms
25g
IEC68-2-29 Eb
Env.Hdbk. 4A: Climatic
and Mechanics
1000 shocks
per 6 directions
Normal
Performance
Shock Non-
operational
halfsine
6ms
100g
IEC68-2-27 3 shocks per
6 directions
Normal
Performance
Table 8: Temperature ranges
Condition Temperature range Notes
Normal Operation
-10°C to +55°C
Specifications fulfilled
Reduced Operation
-20°C to +70°C
Operational only for short periods.
Intermittent Operation
-30°C to +80°C
Operation not guaranteed but an attempt to operate
will not damage the phone.
Storage
-30°C to +80°C
Non operational, 72 h
Table 6: List of external connectors
Connector Name Conn. Manufacturer NMP code / Notes
